Work

Machines with a control loop at the heart.

Gas systems, EV powertrains, smart buildings, consumer products. Each drawing is live — open one and press a button.

A crane sets a folded module on screw pilings beside a two-level modular home. Its cut-away mechanical room shows seven zone dampers, the prefab MEP panel, a touchscreen with jog wheel, and the leak sensor that makes a motorized ball valve shut the water main.

Factory modules fold flat for the flatbed, then a crane sets each one on screw pilings and it unfolds in place. A local rules engine (MQTT, BACnet) runs seven HVAC zones with energy-recovery ventilation, socket-level energy sub-metering and a touchscreen with jog wheel in every room. When a leak sensor gets wet, a rule closes the motorized ball valve on the water main. Temperatures and timings shown are simulated.

Home Modular smart-home construction venture

Deployable Smart Home

A turnkey smart home designed to cut construction cost: foldable factory-built modules, craned onto screw pilings, run from one local server.

Case study

Fig 02 Industrial gas router Live · SIM

Live simulation SIM10/10 chambers in band

Gas Food-grade R&D facility

Industrial Gas Router

A modular system that stores, mixes, analyzes and vents industrial gases, with real-time leak detection across 50+ valves.

Case study

Push Automotive range-extension R&D

Electric Pusher Trailer

Control algorithms for an electric trailer that extends a vehicle's range without hurting its handling, developed on a 1:10 scale rig.

Case study

Nine-view CAD x-ray of the respirator helmet on a mannequin head, showing the full-face visor, shell and rear blower module.

Air Pandemic-era personal protective equipment

Powered Respirator Helmet

A powered air-purifying respirator helmet designed for form as well as function, with custom tooling for small-batch production.

Case study

Vent

Vent Smart-HVAC startup

Decentralized Climate Control

A room thermostat with no room temperature sensor: motorized smart vents estimate each room's temperature from duct readings.

Case study

CAD render of an armored battery enclosure on an aluminum extrusion frame, with lifting eyes, open service hatches and stacked battery modules.

Volt Electric pusher-trailer powertrain

EV Battery Pack

A removable, armored battery system for an electric pusher trailer: four sealed, liquid-cooled packs built from pre-owned OEM EV modules.

Case study

Fig · Core-sampling drill Testbed · torque benchmarkSIM

Drill · compare stock / tuned

ESC

Ready

An off-the-shelf drill rebuilt as a soil core sampler. Its speed controller moved out of the grip into a finned aluminium enclosure, where it can run a higher current limit; with the FOC and MTPA parameters tuned, peak torque rose 50% over stock. The firmware now holds a set speed while the load changes from stratum to stratum. Every other value here, from the curve shapes to the rpm, N·m and depths, is simulated (SIM) for illustration.

Interactive figure (needs JavaScript): an isometric drawing of the altered drill on a stand, coring a soil column cut away to show four strata, beside a torque–speed plot. The relocated, heatsinked controller runs a higher current limit and tuned FOC/MTPA parameters, giving 50% more maximum torque than stock.

Drill Geotechnical field tooling

Core-Sampling Drill

An off-the-shelf drill turned into a precision soil core sampler: regulated speed, 50% more torque, ten units delivered.

Case study

Process diagram of the vacuum-distillation testbed: water heater, flash drum, demister, sight glass, condenser and chilled-water supply, with feedwater, freshwater and brine lines.

Salt Desalination R&D test bed

Tabletop Desalinator

A small-scale, industrial-grade desalination test bed that benchmarks vacuum distillation against vapor recompression on shared utilities.

Case study
